| Item number | TC-3000A |
| General | |
| Frequency Range | 136-174MHZ / 400-520MHZ |
| Channel Capacity | 16 |
| Operating Voltage | 8V DC |
| Operating temperature | -10℃～+50℃ |
| Antenna | High gain antenna |
| Antenna Impedance | 50Ω |
| Mode of operation | Simple or semi-duplex |
| Dimension（H x W x D） | 133*59*36 mm |
| Transmitter | |
| Output power | High≥10W Low≥5W |
| Modulation Type | 16kΦF3E |
| Spurious Radiation | ≤7.5μW |
| Modulated noise | <-40dB |
| Modulation distortion | ＜5% |
| Frequency stability | 5ppm |
| Max. Fr. deviation | ≤±5kHz |
| Current | ≤2600mA |
| Audio response | +6.5~-14dB |
| Adjacent Ch. power | ≥65dB |
| Intermediation sensitivity | 8-12mV |
| Receiver | |
| Sensitivity | ≤0.2μV |
| Occupied bandwidth | ≤16KHz |
| Selectivity | ≥65dB |
| Intermediation | ≥55dB |
| Audio power | 1W |
| Audio Distortion | ≤5% |
| Frequency stability | 5ppm |
| Current | 80mA(when standby) / 220mA(when working) |
| Audio response | +7~-12.5dB |
