| Item number | TC-5000 |
| General | |
| Frequency Range | VHF:136-174MHZ 350-390MHZ / UHF:400-470MHZ 465-520MHZ |
| Operating temperature | -20℃～+50℃ |
| Operating Voltage | 7.2V DC |
| Mode of operation | Simple or semi-duplex |
| Antenna Impedance | 50Ω |
| Weight | 190g(including battery&antenna) |
| Dimension（W x H x D） | 116*57*34 mm |
| Transmitter | |
| RF Output power | 5W/1W |
| Frequency stability | ±2.5ppm |
| Modulation Limiting | ≤5kHz |
| Audio distortion | ＜6% |
| Modulation character | +3dB~-3dB |
| Adjacent Ch. power | ≥65dB |
| Spurious Radiation | ≤7.5μW |
| Occupied bandwidth | ≤16KHz |
| Receiver | |
| Receiving Sensitivity | ≤0.2μV |
| Audio Distortion | ≤6% |
| Audio response | +2dB~-10dB |
| Co-channel suppression | ≥-8 dB |
| Adjacent Ch. Selectivity | ≥55dB |
| Inter-modulation rejection | ≥55dB |
| Spurious response | ≥55dB |
| Audio Distortion | ≥85dB |
