| Item Number | Q1 |
| General | |
| Frequency Range | 400-470MHz |
| Channel Capacity | 16 channels |
| Channel Spacing | 12.5/25kHz |
| Frequency Stability | ±2.5ppm |
| Operating Temperature | -25～+60℃ |
| Antenna Impedance | 50Ω |
| Operating Voltage | 3.7V |
| Dimensions（W×H×D） | 118x60x 35mm |
| Weight | 203.5g(Include battery & antenna) |
| Battery | 1200 (Li-ion Battery) |
| Transmitter | |
| RF output power | 2W±0.3W |
| Modulation Type | 16kΦF3E |
| Modulation Limiting | ≤5kHz |
| Modulation Character | +3dB / -3dB |
| Spurious Radiation | 0.75μW |
| Adjacent Ch. power | ≥65dB |
| Max Fr. Deviation | ≤5kHz |
| Receiver | |
| Receiving Sensitivity | 0.25μV |
| Adjacent Ch. Selectivity | 60dB |
| Inter-modulation | 60dB |
| Co-channel suppression | -8dB |
| Audio Response | +2dB -10dB |
| Audio Output | 500mW |
| Audio Distortion | ≤3% |
